4141107ST Product InformationArlington's zinc die-cast SNAP2IT
fittings are the easiest to insert
snap-on connectors, and handle
the widest variety of cables. Specification SheetCatalog Page E-mail |
Additional Images
Basic Information
| Part Number | 4141107ST |
| Description | Stop wasting time with set screws, locknuts, and clamps. Instead, use Arlington's SNAP2IT line of connectors for quick and easy installations. The tool-less design accepts many cable types, simply snap the cable into the fitting and snap it into the box. That is all there is to it. The fitting is zinc die-cast for strength and longevity and is cULus listed. Fits a 3/4" knockout and supports two cables ranging between 0.525"-0.690" each. |
| UPC | 018997220950 |
| Unit Packaging | 1pc |
| Standard Packaging | 25pcs |
| Country of Origin |  |
| Listing |
|
Physical Information
| Weight | 0.186 lbs/each |
| Height | 2.615" |
| Width | 2.386" |
| Color |  Silver |
| Material(s) | Zinc |
Technical Information
| Line Drawing | 4141107ST Line Drawing |
| Knockout Size(s) | 3/4" |
